Wheel Loader
    ItemUnitFM925
    Overall performance parameters specificationMinimum turning radius mm 5075
    Theoretical Gradeability  °27
    Maximum  speed Km/h36
    Maximum dumping heightmm 3600
    Maximum dump reach

    Discharging distance mm 910
    Discharging angle°44
    Bucket capacity 1.33
    Bucket width/depth mm 2400/620
    Wheel basemm 2865
    Lifting time(unladen)s5.15
    Lowering time(unladen)s3.35
    Discharging time(unladen)s0.7
    Total cycle times9.2
    Maximum digging force kN56.7
    Maximum traction effort kN70
    Maximum breakout forcekN
    Tipping loadkN49.9
    Main dimensions and weight specificationVehicle length mm 7500
    Vehicle heightmm3150
    Vehicle widthmm2430
    Rated loading weightKg2500
    Operating weightKg8200
    Total weightKg
    Minimum ground clearance mm415
    Wheel trackmm1760
    EngineModel
    WP6G125E22
    Manufacturer
    Weichai
    Rated power kW92
    Rated speedr/min2200
    DisplacementL6.75
    Number of cylinders
    6
    Cylinder diametermm105*130
    Maximum torque N.m500
    Minimum fuel consumption rateg/kW. h≤210
    TransmissionModel
    315
    Gearshift
    Front 4 rear 4
    Braking type
    Air brake
    Axle
    2.8 ton axle
    Tire type
    17.5-25
    Front tire air pressureMpa0.33
    Rear tire air pressureMpa0.3
    FuelVolumeL160
    Hydraulic oil L180
    Axle - SingleL14
    Engine L12
    Transmission L28
    Braking system L3
    Steering systemModel
    Full hydraulic steering
    Steering angle °33
    System working pressureMpa18


    The FMAN FM925 wheel loader is designed for heavy-duty operations and is an ideal choice for high-intensity, continuous work scenarios. Whether in mining areas, sand and gravel yards, or large-scale earthmoving projects, it can complete tasks with high efficiency.

    Powerful Load Capacity: A rated load of 2500 kg, combined with a 1.33 m³ large-capacity bucket, allows for larger single-load capacity and significantly reduces the number of work cycles.

    Efficient Power: Equipped with a Weichai 92 kW engine, it provides ample and stable power, maintaining continuous output even during prolonged full-load operation.

    Flexible Loading and Unloading: A 3600 mm discharge height is compatible with various transport vehicles, ensuring a smoother workflow.

    Stable and Reliable: The optimized overall structure and reasonable weight distribution ensure more stable control during heavy-duty operations and enhanced safety.


    Low Operating Costs: Key systems are mature and reliable, maintenance is convenient, reducing downtime and increasing overall value.

    The FM925 perfectly combines high load capacity, powerful performance, and continuous operation capabilities, making it the preferred choice for engineering projects that demand efficiency and durability.
